Fail-Safe® MilBerm™
Heavy-duty construction provides long-term spill containment for vehicles, heavy equipment, tankers and more. Our Fail-Safe® MilBerm™ offers the best in portability and durability.
Download Fail Safe MilBerm Data Sheet
Overview
- Single-piece construction – patented wall-support system integral to berm provides unobstructed work space
- Provides faster deployment – stronger structural integrity
- Quick and easy setup – no assembly required
- Heavy-duty fabric stands up to corrosive solvents and extended wear
- Fail-Safe® flotation device on entry/exit walls, enabling drive-in and drive-out with no need to raise or lower wall
- When in the upright and locked position, wall supports prevent snow and ice from interfering during a spill occurrence
Full Description
The Fail-Safe® MilBerm™ offers superior protection and chemical resistance against the harshest of liquids, including petroleum, oils, greases, and most acids. Unlike floating-wall-type berms that are susceptible to wall collapse and containment failure, the patented design features a stainless-steel brace that supports the wall at a full 90-degree locked position for secure, leakproof containment. A simple push on the walls unlocks the support and lays the wall down for drive-through capability from any angle. The end walls also feature the patented Fail-Safe flotation device that allows the user to leave the entry/exit walls in the down position, weather permitting. This enables the walls to auto-deploy to the upright position using the dynamics of fluid pressure to push the wall up without allowing a spill event. The end walls also include support with locking detent to keep the end walls upright should snow or ice be forecasted.
All military Fail-Safe MilBerms have patented wall designs that maximize usable space inside the berm and greatly reduce any tripping hazard on the berm perimeter. Reinforced CriticalCorner™ design with wraparound diagonal radio frequency welds offers exceptionally strong structural integrity to prevent seam leaks, provide fluid-tight reliability, and extend berm life expectancy. Finished hem edge on top of sidewall prevents fraying and adds strength. Each support includes a heavy-duty brass grommet for anchoring the berm under high wind conditions. Anchor stakes are not included.
MilBerm™ Comparison Chart
Choose TWO Truck Sizes To Compare
Compare Sizes
|
5- or 7-Ton with Fuel Pods |
5- or 7-Ton with Fuel Pods |
2500-Gal HEMTT |
5000-Gal Tanker |
5000-Gal Tanker |
|---|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
Recommended Berm (Part #) |
||||||
|
Recommended Berm (Part #) |
BC3CF-RLFS-1226 SPILL BERM |
BC3CF-RLFS-1230 SPILL BERM |
BC3CF-RLFS-1236 SPILL BERM |
BC3CF-RLFS-1454 SPILL BERM |
BC3CF-RLFS-1456 SPILL BERM |
|
| Dimensions | ||||||
| Dimensions |
12 ft x 26 ft x 1 ft (3.7 m x 7.9 m x 0.3 m) |
12 ft x 30 ft x 1 ft (3.7 m x 9.1 m x 0.3 m) |
12 ft x 36 ft x 1 ft (3.7 m x 11.0 m x 0.3 m) |
14 ft x 54 ft x 1 ft (4.3 m x 16.5 m x 0.3 m) |
14 ft x 56 ft x 1 ft (4.3 m x 17.1 m x 0.3 m) |
|
| Capacity | ||||||
| Capacity |
2333 gal (8831 L) |
2592 gal (9812 L) |
3231 gal (12,231 L) |
5654 gal (21,403 L) |
5864 gal (22,198 L) |
|
| Weight | ||||||
| Weight |
147 lbs (67 kg) |
164 lbs (74 kg) |
190 lbs (86 kg) |
296 lbs (134 kg) |
305 lbs (138 kg) |
|
| Folded Size | ||||||
| Folded Size |
36 in x 36 in x 12 in (914 mm x 914 mm x 305 mm) |
36 in x 36 in x 16 in (914 mm x 914 mm x 406 mm) |
36 in x 36 in x 16 in (914 mm x 914 mm x 406 mm) |
42 in x 36 in x 18 in (1067 mm x 914 mm x 457 mm) |
42 in x 36 in x 18 in (1067 mm x 914 mm x 457 mm) |
|
| NSN | ||||||
| NSN | 4235-01-569-8818 | 4235-01-569-8792 | 4235-01-569-8833 | 4235-01-550-3802 | 4235-01-569-8846 | |
